iStarUSA E-306L 3U E-ATX 6 x 5.25" Bays Rackmount Chassis (Power Supply Not Included) (E-306L)

Istore > Networking > Server Case / Rackmount Chassis > iStarUSA E-306L 3U E-ATX 6 x 5.25" Bays Rackmount Chassis (Power Supply Not Included)

(Click picture to enlarge)

We do our best to ensure accuracy of this product's picture and information. We will ship products based on the product name and model number.

iStarUSA E-306L 3U E-ATX 6 x 5.25" Bays Rackmount Chassis (Power Supply Not Included)

SKU #: 136333

Model #: E-306L
Product #: ISTA081

Our Price:$370.31

Alternate View (Click picture to enlarge)

Description

Product Data Sheet

Features
- 80mm x4 and 60mm x2 Cooling Fans
- 1.2mm Steel Body Chassis
- Power and Alarm Reset Switch
- Power LED Indicators
- Supports Front Access USB2.0 x2
- Supports E-ATX Motherboard

Product Introduction
E-306L rackmount chassis is designed with six 5.25" drive bays Indicatorsand three 3.5" drive bays. combined with BPU 3.5" to 5.25" hdd cages provides up to 13 x 3.5" hard drives or SSDs capability for any RAID configuration. Four 80mm fans is equipped with E-306L to provide the best air ventilation preventing critical equipment from heat damage. E-306L also supports E-ATX motherbaord and redundant power supply to provide maximum reliability and performance for server applications.

Specification
Model Number : E-306L
RoHS Compliance Version : Yes
Standard Drive Bays :
- 3.5" Drives: 3
- 5.25" Drives: 6
Indicators : Power
Switches : Power, Reset
Expansion Slots : 7
Material of Front Bezel : Aluminum
Material of Handle : Aluminum
Material of Main Chassis : Zinc-Coated Steel SECC 1.2mm
Color of Main Chassis : Black
Front Connector : 2x USB 2.0
Motherboard Size : 12 x 13 (EATX, ATX, microATX)
Cooling Fan : 2x60mm, 4x80mm
Ordering Information (Part Number)
- with 400W 2U Redundant PSU:E306L-24R-40R2U
- with 460W 2U Redundant PSU:E306L-24R-46R2U
- with 80 Plus 500W Redundant PSU:E-306L-50R2U8
- with 80 Plus 600W Redundant PSU:E-306L-60R2U8
- with 80 Plus 700W Redundant PSU:E-306L-70R2U8
- with 80 Plus 800W Redundant PSU:E-306L-80R2U8
- with 80 Plus 950W Redundant PSU:E-306L-95R3K8
Dimensions (WxHxD) : 19.00" x 5.19" x 25.10" (482.6 mm x 131.8 mm x 637.5 mm)
